Trailmaster Cheetah 6 Youth Go-Kart, 163cc Engine, 4-Stroke Single Cylinder, Air Cooled, Remote Start/Kill

$1,400

In stock

SKU: 7cf4abbott Category:

Trailmaster Cheetah 6 Youth Go-Kart, 163cc Engine, 4-Stroke Single Cylinder, Air Cooled, Remote Start/Kill

Introducing the TrailMaster Cheetah 6, a sleek and sporty youth go-kart designed for adventure seekers aged 6-12 years old and up to 5’4″ tall. Smaller than the Cheetah 8, the Cheetah 6 is built for young riders who are ready to experience off-road thrills in a safe, comfortable, and exciting way. Powered by a 163cc, 5.5 HP horizontal OHV engine with a torque converter CVT transmission, this go-kart delivers smooth acceleration and can reach a top speed of up to 25 mph.

Safety is a top priority with the Cheetah 6, which features a 4-point safety seatbelt system, hydraulic rear disc brakes, and a parking brake for extra peace of mind. The adjustable seat allows for a customizable fit, with the pedal-to-seat back distance adjustable from 28″ to 32″. Equipped with a manual choke, this go-kart is easy to start even in cold weather, and the electric start with a pull-start backup ensures reliable operation in any condition.

Key features of the TrailMaster Cheetah 6 include:

  • Sporty, Stylish Design: Eye-catching body panels and LED headlight package make this go-kart as cool as it is functional.
  • Adjustable Seat: Pedal-to-seat back distance adjustable from 28″ to 32″, accommodating riders up to 5’4″.
  • 4-Point Safety Seatbelt System: Provides secure and safe riding for young drivers.
  • Electric Start with Pull Start Backup: Convenient starting options for any situation.
  • Fully Automatic CVT with Reverse: Simple to drive with effortless shifting and reverse capability.
  • 163cc, 5.5 HP Horizontal OHV Engine: Delivers reliable power and performance, ideal for young riders.
  • Manual Choke: Ensures easy starts even in cold weather.
  • Hydraulic Rear Disc Brake: Provides strong, reliable stopping power.
  • Max Speed of 25 mph: Perfect for safe yet thrilling rides.
  • Bikini Sunshade Top: Provides shade and protection during outdoor adventures.
  • Additional Features: Remote start/kill switch, speed governor, fenders, and cargo rack for added convenience and safety.



Specifications

Engine Information

  • EPA Certification: Yes
  • Engine Type: 4-stroke, single-cylinder, air-cooled, Horizontal OHV Engine
  • Displacement: 163cc, 5.5HP
  • Max HP: 3.2KW/3600RPM
  • Max Torque: 10.8NM/2800RPM
  • Bore x Stroke: 2.67 x 1.77 inches
  • Max Speed: 24 mph
  • Climbing Ability: 12 degrees
  • Starting System: Electric or Pull
  • Battery: YTX12-BS, 12V 10Ah
  • Carburetor Brand: P19
  • Engine Oil: SAE 10W-40

General Information

  • Clutch: Automatic torque converter CVT with reverse
  • Driveline / Driving Wheel: Chain / Dual wheel drive
  • Suspension (Front/Rear): Double A-arm / Swing-arm
  • Brake: Rear disc
  • Tires (Front/Rear): 145/70-6 / 16*6-8
  • Wheel: Steel
  • Fuel Capacity: 1 gal
  • Weight (Gross/Net): 308 / 264 lbs
  • Max Load: 200 lbs

Dimension Information

  • Wheelbase: 43.7 inches
  • Overall Dimensions (L x W x H): 63 x 36 x 50 inches
  • Height to Seat: 14.2 inches
  • Minimum Ground Clearance: 3.6 inches
  • Pedal to Seat Back Distance: 28” to 32”
